400
Alloy 400 is a ductile nickel-copper alloy with resistance to a wide range of corrosive environments. This grade is often chosen to handle sulfuric acid through 80% concentration at room temperature, and about 15% H2SO2 boiling. Alloy 400 possesses useful resistance to aerated hydrochloric acid up to 10% concentration at room temperature. The alloy has excellent resistance to sea or brackish water under high-velocity conditions. Alloy 400 is one of the few materials with good resistance to hydrofluoric acid.
Features
Forms
Applications
Specifications
Common Trade Names
Literature
Features
- Resistant to a variety of corrosive environments
- Freedom from chloride stress corrosion cracking
- Good strength and toughness over a wide temperature range
- Useful resistance to dry chlorine, fluorine hydrogen chloride and hydrogen fluoride gases
Forms
400 Pipe, 400 Plate, 400 Sheet, 400 Weld Wire
Applications
- Crude oil distillation towers
- Marine components
- Valve and pump components
- Chemical processing equipment
- Caustic evaporators
- Oil and gas applications
- Hydroflouric acid production
- Salt production equipment
Specifications
ASME SB: 366, 725, 127, 164, 165
ASTM B: 127, 164, 165, 366, 725
ISO: 15156-3
NACE: MR0175
UNS: N04400
Common Trade Names
Monel 400, Alloy 400
Literature
